Home > Rackmount Accessories > Rail Sections > 2 Sections Telescopic Ball-Bearing Server Rail for " Odd U " (1U/ 3U/ 5U)

2 Sections Telescopic Ball-Bearing Server Rail for " Odd U " (1U/ 3U/ 5U)

19",rackmount,rack-mount,rack,racks,rail,accessory
Accessories:

Feature：
These server rails can be mounting in all cabinets with pairs of mounting angles through brackets for server rails & mounting onto the cabinet / rack that provides a pair of telescopic rail smooth reliable & convenience operation .

Supply Included：

  • A pair of server rail
  • 2 pair of brackets
  • Assembly parts

    • Meterial：

    Sheet Steel

    Finished:

    Powder coating in color RAL 7035 or RAL 9011
    CLM Part No. Cabinet Depth Rail Depth For Height
    882051-618 600mm 18" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-718 700mm 18" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-818 800mm 18" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-918 900mm 18" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1018 1000mm 18" 1U/ 3U/ 5U
    7U/ 9U/ 11U

    882051-720 700mm 20" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-820 800mm 20" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-920 900mm 20" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1020 1000mm 20" 1U/ 3U/ 5U
    7U/ 9U/ 11U

    882051-722 700mm 22" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-822 800mm 22" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-922 900mm 22" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1022 1000mm 22" 1U/ 3U/ 5U
    7U/ 9U/ 11U

    882051-824 800mm 24" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-924 900mm 24" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1024 1000mm 24" 1U/ 3U/ 5U
    7U/ 9U/ 11U

    882051-826 800mm 26" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-926 900mm 26" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1026 1000mm 26" 1U/ 3U/ 5U
    7U/ 9U/ 11U

    882051-928 900mm 28" 1U/ 3U/ 5U
    7U/ 9U/ 11U
    882051-1028 1000mm 28" 1U/ 3U/ 5U
    7U/ 9U/ 11U
