| Pend No. | Taiwan 0314216 |
| Specifications：(Meets F.C.C.Class A & CE & RoHS) | |
| Power Supply | PS2 AT Dual Redundant (Vertical) |
| Fans | 2 pcs x 120 x 120(mm) |
| Switches: | Power ON/OFF, Buzzer Reset |
| Drive Bays | 8 x5.25"(Horizontal), Removable |
| Vibrator | 8 Sets against vibrator , patent pended |
| Indicators | Redundant power ault(Primary) Redundant power fault(Redundant) Disk Drive status, Redundant power on(Primary) Redundant power on(Redundant) |
| Front Panel | 8 pcs Blanking Panels ,patent pended |
| Side Part | A pair of slide rail decorations |
| Cable | Option cable for SCSI or IDE as request |
| Material | SPEG |
| Finished | Black(RAL 9011) Beige(RAL 7035) |
| Dimension | Inch：19"x18"x8.75"(WxDxH) |
| Shipping Dimension | 1PC / CTN / 4.5 CUFT |
| Weight | N.W.: 15 KGS G.W.: 18 KGS |
