| Specifications：(Meets F.C.C.Class A & CE & RoHS) | |
| Power Supply | Single ATX/PS2 Power Max 860 (Depth: 160mm) (Optional) Mini Redundant Power Max 600 Watts (Depth: 160mm) (Optional) |
| Motherboard | Max to 12" (W) x 13" (D) Compliant ATX/SSI EEB 3.61 |
| Fans | Front : none Middle : none Rear : 2 x Axial (140 x 140 x 25mm) |
| Indicatiors LEDs | 1 x Disk status LED 1 x Power LED 2 x NIC LEDs 1 x Fan Fault LED |
| Switches | Power Button ON/OFF Reset Button ON/OFF |
| Drive Bays | 2 x 5.25" CD-ROM 1 x 3.5" Floppy 2 x 3.5" Hard Disks (internal) |
| Front USB port | 4 USB Ports with Cable (option) |
| Expansion Slot | Full Size PCI & PCI Express Card |
| Air-Filter | Chemical filter washable |
| Material | SECCESAXZ Standard (ROHS) |
| Finished | Black(RAL 9011) Beige(RAL 7035) |
| Temperature | 0°C(32F) ~ 50° C(122F) (Non-operation) |
| Humidity | 5%~95% Non-Condensing |
| Dimension | MM:
(W)424 x (H)177 x (L)432 INCH: (W)19" x (H)6.97" x (D)17" |
| Shipping Dimension | MM:
(W)546 x (H)307 x (L)569 INCH: (W)21.5" x (H)12.09" x (D)22.4" |
| Product Applications | Web Server Proxy Server VPN Gateway High-End Workstation Print Server |
