| Specifications：(Meets F.C.C.Class A & CE & RoHS) | ||
| Power Supply | 1U Single Power with 190~205mm Depth (Optional) | |
| Motherboard | Max to Mini-ITX | |
| Fans | Rear 3x (60*60*15MM) Front 1x Blower(97*94*33MM) |
|
| Indicatiors LEDs | 1xDisk status LED 1xPower LED MIC 1 LED MIC 2 LED |
|
| Front Panel | Power Button ON/OFF Reset Button ON/OFF 2* USB port (Optional) |
|
| Drive Bays | 2x3.5" Hard Disk 1*5.25" CD-ROM 1* Slim CD-ROM |
|
| Material | SECCESAXZ Meet RoHs,CE,UL | |
| Finished | Black(RAL 9011) Beige(RAL 7035) |
|
| Chassis Dimension | MM:
(W)429x(H)66x(D)382 INCH: (W)19"x(H)2.59"x(D)15" |
|
| Shipping Dimension | MM:
(W)584x(H)172x(L)513 INCH: (W)23"x(H)6.78"x(D)20.2" |
|
| Weight | N.W：N/A G.W：N/A |
|
| Product Applications | Web Server Firewall Server Proxy Server VPN Gateway DNS Server ISP Email Server High-End Workstation |
|
| Riser Card (Optional) | 2 x 32 bit PCI 5V | |
