| Specifications：(Meets F.C.C.Class A & CE & RoHS) | |
| Power Supply | 1U Flex Power Supply |
| Motherboard | Support Mini-ATX (Max 170mmx 170mm) (6.7" x 6.7") |
| Fans | Rear 2x (40x40x20MM) |
| Front Panel | Power Button ON/OFF Reset Button ON/OFF |
| Indicatiors LEDs | 1xDisk Drive status LED 1XPower LED NIC LED1 NIC LED2 |
| Drive Bays | 1x3.5" Hard Disk |
| Switches | Power ON/OFF Reset ON/OFF |
| Temperautre | 0℃ ~ 45℃ Environment Temperature |
| Material | SECCESAXZ Meet RoHs,CE,UL |
| Finished | Black(RAL 9011) Beige(RAL 7035) |
| Chassis Dimension | MM:
(W)429 x (H)44 x (D)228 INCH: (W)19" x (H)1.73" x (D)9.5" |
| Riser Card (Optional) | 1 x 32 bit PCI 5V or 1x PCI-E(16x,8x,4x,1x) |
